Galvanized Security Barbed Wire With Blades Stainless Steel Razor Type

Razor Wire has a central strand of high tensile strength wire, and a steel tape punched into a shape with barbs. The steel tape is then cold-crimped tightly to the wire everywhere except for the barbs. Razor Wire is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans.

The diameter of the razor wire coils can range from 18 inches to 60 inches, while 30-inch products are among the most often specified for medium or high security applications. Concertina configuration is available, which makes the razor wire barrier much more dense and difficult to penetrate. It is almost vital for products of 30 inch diameter and greater. Please tell us the specifications of Razor Wire that you need and we constantly strive to exceed the expectations of our customers.

How to install Razor wire in 8 steps:

Important: Before installing concertina rolls, always use work gloves to protect your hands. Gloves with reinforced palms are ideal to help protect your hands when catching the concertina wire.

Razor Blade Type Specification
Reference Number	Thickness	Wire Dia.	Barb Length	Barb Width	Barb spacing
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-15	0.5±0.05	2.5±0.1	15±1	15±1	33±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-30	0.5±0.05	2.5±0.1	25±1	16±1	40±1
CBT-25	0.5±0.05	2.5±0.1	30±1	18±1	45±1
CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

Standard Production Type
Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	8M	CBT-60.65	Single coil
500mm	41	10M	CBT-60.65	Single coil
700mm	41	10M	CBT-60.65	Single coil
960mm	53	13M	CBT-60.65	Single coil
600mm	86	14M	BTO-10.22.25.30	Cross type
700mm	72	12M	BTO-10.22.25.30	Cross type
800mm	64	10M	BTO-10.22.25.30	Cross type
960mm	52	9M	BTO-10.22.25.30	Cross type

Main Advantage:

(1)High security Barbed razor wire with the sharp razor guarantees a high security whilst retaining high quality.
(2)Long life Razor wire material of stainless steel or hot-galvanized makes sure for long life and low maintenance.
(3)Easy installation Short sections needed for urgent security can be installed extremely fast and with little equipment, allowing repairs to be carried out without compromising perimeter security.

1. compression rolls, 5rolls, 10rolls, or more rolls as one bundle

2. water-proof paper inside with woven bag outside

3. 1roll, 3rolls or 5rolls in one carton

4. as customer request
